TEKNO R4 SAE 100 R4

Vitillo
Code THR412 D.N 19 Hose Size

19.0 mm
3/4”

Outside Diameter 32.0 mm Max Working Pressure 21 bar Price Quantity
Available on Request
Code THR416 D.N 25 Hose Size

25.4 mm
1”

Outside Diameter 37.0 mm Max Working Pressure 17 bar Price Quantity
Available on Request
Code THR420 D.N 31 Hose Size

32.8 mm
1 1/4”

Outside Diameter 45.0 mm Max Working Pressure 14 bar Price Quantity
Available on Request
Code THR424 D.N 38 Hose Size

38.2 mm
1 1/2”

Outside Diameter 52.0 mm Max Working Pressure 10 bar Price Quantity
Available on Request
Code THR432 D.N 51 Hose Size

50.8 mm
2”

Outside Diameter 64.0 mm Max Working Pressure 7 bar Price Quantity
Available on Request
Code THR440 D.N 63 Hose Size

63.5 mm
2 1/2”

Outside Diameter 77.0 mm Max Working Pressure 4 bar Price Quantity
Available on Request
Code THR448 D.N 76 Hose Size

76.2 mm
3”

Outside Diameter 90.5 mm Max Working Pressure 4 bar Price Quantity
Available on Request
Code THR464 D.N 102 Hose Size

101.6 mm
4”

Outside Diameter 116.5 mm Max Working Pressure 2 bar Price Quantity
Available on Request
  • Hose Type: Textile braided hose
  • Application : Delivery of Oil in Hydraulic Systems - Suction Lines
  • Available Cover : Standard
  • Available Cover Color : Black
  • Operating Temperature Range: - 40°C/+100°C (-40°F to +212°F)
  • Tube : Oil resistant synthetic rubber
  • Reinforcement : 2 high tensile textile braids and 1 high tensile steel spiral
  • Cover : Weather resistant special synthetic rubber

PLEASE NOTE: The price shown is per metre of hose, the maximum single coil length is 100m for 1/4″, 3/8″, 1/2″ & 3/4″, 50m for 1″
